| Brand Name: | Henrriet |
| Model Number: | HRY-300T |
| MOQ: | 1 |
| Price: | Online/offline communication |
| Payment Terms: | T/T |
Product Description:
The two-layer hot press represents a significant advancement in industrial bonding technology, engineered to fuse and cure multi-layered materials under precisely controlled high-temperature and high-pressure conditions. This system is indispensable in manufacturing engineered wood panels, decorative surfaces, and composite materials, catering to industries that demand uniformity and structural integrity. Unlike conventional manually operated presses, it multiplies daily output dramatically, positioning it as an ideal solution for enterprises handling large-order volumes with stringent deadlines.Innovative energy-efficient features include advanced thermal insulation enveloping the platens to minimize heat dissipation, coupled with an adaptive temperature control system that dynamically modulates heating power based on real-time load requirements. This intelligent energy management ensures operational efficiency, allowing the machine to consume less energy than multiple standalone units combined.
Machine parameters
| Maximum Pressure | 300T (customizable) |
| Layer | 2 |
| Worktable Sizes | 2300mm*1700mm (customizable) |
| Maximum temperature | 100℃ |
| Layer Spacing | 200mm |
| Power supply | 380V/50Hz, three-phase |
| Heating Power | 54KW(customizable) |
| Hydraulic power | 5.5KW(customizable) |
| High Temperature Oil Pump Motor Power: | 2.2KW (customizable) |
| Dwell time | 0-99.99 hours (Adjustable) |
| Platen lift speed | 10-12mm/s |
| Pressure accuracy | ±1% (ISO-compliant) |
| Size | 2830*1700*3120mm |
| Weight | 15000KG |
Service Support
Warranty: 1 year
Packaging: Film with foam
24-hour customer service hotline, respond to repair needs within 48 hours.
Free video training for operators and provision of process guidance manuals.
Lifetime technical support and software upgrade services.
