60t Maximum Pressure Cold Press Machine with 3600mm Processing Length and Automated Material Handling for Sandwich Panels

60t Maximum Pressure Cold Press Machine with 3600mm Processing Length and Automated Material Handling for Sandwich Panels

Brand Name:	Henrriet
MOQ:	1
Price:	Online/offline communication
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Packaging Details:

Film with Foam

Highlight:

aluminum honeycomb board cold press machine

plywood track sliding table press

artificial board cold press machine

Product Description

Aluminum Honeycomb Board Artificial Board Plywood with Track Sliding Table Cold Press Machine

Product Overview

The automatic feeding sliding table cold press is a fully automated cold-forming system purpose-engineered for sandwich-structured building panels, including color steel rock wool composite panels, polyurethane insulation boards, and other multi-layer composite constructions.

This machine directly addresses persistent industry challenges that have long plagued traditional cold press operations: intensive manual handling with high labor requirements, sluggish production cycles, inaccurate material alignment leading to panel misalignment and edge mismatch, uneven pressure distribution resulting in core material collapse, panel delamination and surface hollowing, logistical difficulties in handling large-format panels, and excessive waste of high-value raw materials.

Key Features

Superior Production Capacity: Fully automated material handling architecture transforms production workflow from labor-dependent manual operations into a continuous, high-throughput process. Heavy-duty automated conveying and positioning with servo automatic alignment for zero-misalignment precision.
Integrated Safety and Protection: Comprehensive safety protocols engineered for heavy-duty panel processing. Rugged construction for industrial environments with electrical system safety including overload protection, short circuit protection, and phase loss protection.
Wide-Ranging Application Versatility: Handles sandwich panel production with metal/non-metal multi-layer composites and purification/cleanroom board applications for high-performance controlled environment panels.
Easy Maintenance and Technical Support: Systematic preventive maintenance procedures with regular conveyor system inspection and maintenance to ensure sustained equipment reliability.

Technical Specifications

Specification	Value
Maximum Pressure	60t
Pressure Plate Size	3600mm * 2200mm
Maximum Processing Length	3600mm
Maximum Processing Width	2200mm
Maximum Processing Thickness	800mm
Lower Workbench Height	300mm
Oil Cylinder Specifications	6 pcs (70mm * 100mm)
Power	5.5KW
Overall Dimensions	4100mm * 2500mm * 2900mm

Competitive Advantages

Two In-House Factories: Better prices and faster delivery with no middlemen or markups. You buy straight from the source with full control over production speed and costs.
Custom-Built Solutions: More than 30 senior engineers design machines around your actual production needs, floor space, and budget.
Global Certification: CE & ISO 9001 certified, meeting EU safety standards and quality requirements for international compliance.
Proven Experience: More than 50 countries, 1000+ projects with equipment engineered for long-term, heavy-duty use in real factories worldwide.
