| Brand Name: | Henrriet |
| Model Number: | HRY-30T/1Layer |
| MOQ: | 1 |
| Price: | Online/offline communication |
| Payment Terms: | T/T |
Artificial Quartz Stone Slab Acrylic Sheet Metal Sheet Hot Press Transfer Printing Machine
Product Description:
This advanced thermal transfer press is designed to permanently emboss decorative surfaces onto rigid composite substrates—such as quartz, granite, metal, and acrylic panels. By combining controlled heat, pressure, and precision-engineered mold technology, it imparts detailed wood grains, natural stone patterns, leather textures, and custom geometric designs directly into the material. The result is a high-end decorative finish with striking visual and tactile qualities.Using high-fidelity molds and stable pressing control, the equipment reproduces complex patterns—including marble, travertine, and woodgrain effects—with depth, clarity, and seamless continuity. The finish offers a premium aesthetic that exceeds the limitations of conventional printing or coating methods.During the pressing process, the surface layer is densified, which enhances key performance characteristics such as abrasion resistance, scratch resistance, stain protection, and moisture impermeability. These attributes make it particularly well-suited for high-use settings including kitchen countertops, bathroom installations, and commercial flooring.
Machine parameters
| Max pressuer | 30T(Controllable) |
| Work platen size | 3600mm*1800mm*50mm |
| Systm pressure | 20mpa |
| Max.platen opening | 300mm |
| Maximum temperature | 180℃(Ambient Temperature-180℃ Controllable) |
| Oil cylinder specification | 80mm*60mm * 6pcs |
| Hydraulic pump power | 4kw |
| Hot oil pump power | 3kw |
| Heating pipe power | 90kw |
| Overall dimensions | 4410*2250*2830mm |
| Weight (about) | 8200kg |
Service Support
Warranty: 1 year
Packaging: Film with foam
24-hour customer service hotline, respond to repair needs within 48 hours.
Free video training for operators and provision of process guidance manuals.
Lifetime technical support and software upgrade services.
