Two-component Polyurethane Gluing Machine Plywood Sandwich Composite Board Bonding
Product Description:
With excellent performance, the two-component automatic gluing machine becomes the right assistant to the composite panel, plywood and sandwich panel manufacturers. We are committed to providing you with a stable, reliable, trouble-free and efficient gluing solution through technical innovation to comprehensively improve your production efficiency and product quality.
Excellent production capacity, supporting efficient production
Accurate proportioning and uniform mixing: Using a high-precision measuring system, ensure that the A and B component adhesives are accurately mixed according to the preset ratio,, ensuring stable adhesive performance from the source and avoiding product defects caused by improper proportion.
Fast response, flexible adaptation: Supports multi head parallel dispensing and multi axis linkage control, can flexibly adapt to different production line layouts and product specifications, easily deal with complex curved workpieces, and enhance production flexibility.
Multiple security measures to safeguard human-machine safety
Intelligent protection and fault warning: The equipment integrates multiple safety protection and alarm functions such as overload, emergency stop, phase loss, overvoltage and undervoltage, and monitors key parameters in real time to effectively prevent potential risks
Reliable structure and stable operation: The main electrical components are from internationally renowned brands such as Siemens, Omron, Schneider, etc. The core components have been repeatedly verified to ensure long-term stable operation of the equipment.
Widely applicable, one machine with multiple uses
Strong material compatibility: optimized for uniform coating of composite panels, plywood, sandwich panels, aluminum honeycomb panels, laminated panels and other materials.
Wide adaptability of adhesive: It can adapt to various two-component adhesives such as epoxy resin and polyurethane, and the equipment configuration can match the characteristics of adhesives with different viscosities, mixing ratios, and curing conditions.
Easy to maintain, worry free and effortless
Intelligent diagnosis and cleaning: equipped with automatic fault alarm function and self-cleaning function, simplifying cleaning work and effectively reducing downtime.
Machine parameters
| Gel Dripping Width | 200-1300mm(customizable) |
| Coating Speed | 1-12 meters per minute(adjustable) |
| Gel Dripping Length | 300mm-4500mm(customizable) |
| Product Width | 200mm-1300mm(customizable) |
| Ratio Adjustment | Mixing ratio between 2:1-5:1 (adjustable) |
| Environmental Requirements | Temperature 5-45 ℃, humidity ≤ 80% |
| Effective Volume of AB Tanks | 40L (automatic feeding) |
| Glue Consumption per Square Meter | 200g-450g(adjustable) |
| Conveyor Line | Width 1300mm, height 850mm ± 50mm, length customizable |
| Adhesive Viscosity | 4000-12000CPS (customizable) |
| Power | 5.75kw |
| Control Method | PLC programming+touch screen |
Service Support
Warranty: 1 year
Packaging: Film with foam
24-hour customer service hotline, respond to repair needs within 48 hours.
Free video training for operators and provision of process guidance manuals.
Lifetime technical support and software upgrade services.
